The 10 layer thick copper coil PCB board for automobiles is a high-performance printed circuit board designed specifically for automotive electronic applications. The product adopts multi-layer structure and thick copper technology, aiming to meet the strict requirements of the automotive industry for high power, high reliability and environmental resistance, and is widely used in electric vehicles, auto drive system, on-board electronic equipment and other fields.
Main Features
1.10 layers design: Adopting a 10 layer PCB structure, providing higher wiring density and better signal integrity. Effectively reduces signal interference and crosstalk, improving overall performance.
2. Thick copper technology: Copper thickness is usually 3oz (about 105 μ m) or higher, suitable for high current applications. Provide better heat dissipation performance to meet the needs of high-power electronic devices.
3. High temperature and environmental resistance performance: High temperature resistant materials are used to ensure stability in the working environment of automobiles. It has good moisture resistance, earthquake resistance, and chemical corrosion resistance, and can adapt to various harsh environments.
4. Excellent electrical performance: Designed to support high-speed signal transmission, suitable for onboard communication and control systems. Adopting appropriate impedance control and differential signal design to ensure signal integrity.
5. Multiple surface treatments: Provides various surface treatment options, such as ENIG, HASL, OSP, etc., to meet different customer needs.
Adapt to different welding processes and environmental requirements.
Technical Specifications
Number of layers: 10
Materials: FR-4, SY1000-2
Thickness: 5.0mm
Copper thickness: inner 5, outer 5 oz
Color: green solder mask and white silkscreen
Half hole process: 4.0mm
Dielectric constant: between 4.0 and 4.5
Surface treatment: ENIG
Application field
Electric vehicles: used for battery management systems, charging modules, and electric drive systems.
Autonomous driving: applied in sensors, control units, and communication modules.
In car electronics: suitable for information entertainment systems, navigation systems, and in car controllers.
Safety system: used for critical safety components such as car airbags and ABS systems.
Conclusion
The 10 layer thick copper coil PCB board for automobiles is a high-performance and highly reliable product designed to meet the high power and high-density wiring requirements of modern automotive electronic devices. Its advanced thick copper technology and excellent electrical performance make it an ideal choice for the automotive industry, providing stable support for various in car electronic devices.
