A 2-layer universal electronic circuit breadboard PCB is a circuit board designed specifically for electronic prototyping and experimentation, with a double-layer structure that provides higher connection density and more complex circuit design capabilities. Suitable for education, research and development, and DIY projects, helping users quickly build and test circuits.
Product Features
1. Double layer design
High density connectivity: The double-layer design allows for more components and connections, making it suitable for the construction of complex circuits.
Better wiring capability: It can be wired between different layers, reducing interference and signal loss.
2. No welding interface
Quick assembly: Users can easily insert and remove components without welding, saving time.
Suitable for beginners: The solderless design reduces the entry barrier and is suitable for e-learning and experimentation.
3. Strong compatibility
Supports multiple components: compatible with various electronic components such as resistors, capacitors, diodes, integrated circuits, etc.
Adapt to multiple power sources: support multiple voltage inputs to meet different circuit requirements.
4. Durable materials
High quality PCB material: using high-quality FR-4 material to ensure durability and stability.
Anti oxidation treatment: Surface treatment can prevent oxidation and extend the service life.
Technical Specifications
Number of layers: 2
Plate thickness: 1.6mm
board: KB-6160
Copper thickness: 1/1oz
Minimum line width and spacing: 0.4/0.4mm
Minimum aperture: 0.3
Surface treatment: immersion gold
Process key points: none
Application field
Education: Used for experiments and practices in electronic courses to help students understand circuit principles.
Prototype design: Engineers can quickly validate and modify circuit designs.
DIY project: Enthusiasts can freely combine components to create personalized circuits.
summary
A 2-layer universal electronic circuit breadboard PCB is a powerful tool suitable for various electronic experiments and prototype designs. Its double-layer design provides higher flexibility and connectivity, making it an indispensable device in education, research and development, and DIY projects. Whether for learning or development, 2-layer breadboards can meet the needs of users.
